Garden-Fish Ponds Large 30" Elite Waterfall Box

Large 30" Elite Waterfall Box

SKU:
PB1090
|
UPC:
897570001090
$849.99
(No reviews yet) Write a Review

Made in the USA

  • Waterfall width: 30-inch spillway
  • Dimensions: 31.75" × 40.5" × 25.75"
  • Maximum recommended pump flow: 10,000 GPH
  • Maximum pond volume: 6,000 gallons
  • Inlet fittings: Two 3-inch spinwelds
  • Warranty: Lifetime limited plastics warranty
Current Stock:
Description
Contractor-grade biological filtration and a 30-inch waterfall

Large 30" Elite Waterfall Box

Build a broad, natural-looking pond waterfall while adding biological filtration to the recirculating system. The Large Elite Waterfall Box is sized for ponds up to 6,000 gallons, accepts up to 10,000 GPH and includes a landscape lid that helps the installed box disappear into the surrounding rockwork and planting.

Spillway: 30 inches
Maximum flow: 10,000 GPH
Pond capacity: Up to 6,000 gal.
Inlets: Two 3-inch spinwelds
Model: PB1090

Built for High-Flow Pond Waterfalls

Filtration and Waterfall in One

Water enters through the lower plumbing connection, moves through the filter media and returns to the pond across the detachable 30-inch spillway.

Flexible Plumbing Layout

Two side spinweld fittings let you bring the feed line in from either direction. The second fitting can be plugged, used for a second pump line or configured for back-flushing.

Easier to Conceal

The faceted box profile and included landscape lid help integrate the filter into a berm, stream head or pond edge while preserving access for maintenance.

What Comes with the Waterfall Box

The supplied parts support installation of the box and its liner connection. The biological media that fills the mesh bag is selected separately.

Installation hardware
  • Male plumbing adapter and threaded plug
  • Self-tapping stainless steel screws and screw caps
  • Liner clips
  • Black silicone and Teflon thread tape
  • Installation instructions

Made in the USA.

Large Elite Specifications

SKU: PB1090
UPC: 897570001090
Spillway width: 30 inches
Overall dimensions: 31.75" × 40.5" × 25.75"
Maximum recommended flow: 10,000 GPH
Maximum pond volume: 6,000 gallons
Inlet fittings: Two 3-inch spinwelds
Accepted flex pipe: 2- or 3-inch flexible PVC
Recommended loose media: 5 cu. ft. Bacti-Twist, sold separately
Waterfall box warranty: Lifetime limited plastics warranty

Compare Waterfall Box Sizes

Choose the model around the pond volume, planned waterfall width and actual pump flow at the installed head height. Maximum flow is a box limit, not a promise that every pump will produce that flow after plumbing and elevation losses.

Specification DIY 1200 DIY 1500 DIY 2000 Small Elite Medium Elite Large Elite Extra Large Elite
Spillway 14" 14" 20" 14" 22" 30" 40"
Dimensions 19" × 15.5" × 14.5" 20.5" × 20" × 15.75" 22" × 23" × 19" 23" × 24.75" × 21.75" 31" × 30.5" × 23" 31.75" × 40.5" × 25.75" 35.75" × 50" × 30.75"
Maximum flow 2,000 GPH 2,500 GPH 4,500 GPH 3,500 GPH 6,000 GPH 10,000 GPH 20,000 GPH
Filters up to 1,200 gal. 1,500 gal. 2,000 gal. 1,500 gal. 3,500 gal. 6,000 gal. 10,000 gal.

DIY 1200

Spillway: 14"

Dimensions: 19" × 15.5" × 14.5"

Maximum flow: 2,000 GPH

Filters up to: 1,200 gal.

DIY 1500

Spillway: 14"

Dimensions: 20.5" × 20" × 15.75"

Maximum flow: 2,500 GPH

Filters up to: 1,500 gal.

DIY 2000

Spillway: 20"

Dimensions: 22" × 23" × 19"

Maximum flow: 4,500 GPH

Filters up to: 2,000 gal.

Small Elite

Spillway: 14"

Dimensions: 23" × 24.75" × 21.75"

Maximum flow: 3,500 GPH

Filters up to: 1,500 gal.

View Small Elite

Medium Elite

Spillway: 22"

Dimensions: 31" × 30.5" × 23"

Maximum flow: 6,000 GPH

Filters up to: 3,500 gal.

View Medium Elite

Large Elite — Current Model

Spillway: 30"

Dimensions: 31.75" × 40.5" × 25.75"

Maximum flow: 10,000 GPH

Filters up to: 6,000 gal.

Extra Large Elite

Spillway: 40"

Dimensions: 35.75" × 50" × 30.75"

Maximum flow: 20,000 GPH

Filters up to: 10,000 gal.

View Extra Large Elite

Installation at a Glance

Review the complete installation guide before excavation or liner cutting. This built-in component must be supported, leveled, plumbed and sealed correctly.

Choose the Location

Place the waterfall opposite the skimmer for pond circulation, either at the pond edge or at the head of a stream. Confirm viewing angles and access for future media cleaning.

Prepare and Position

Compact the support area to reduce settling. Keep the box level from side to side and tilt it slightly forward—about one-quarter bubble—so water travels evenly toward the spillway.

Connect the Plumbing

Choose the inlet side, tape the threaded male adapter and plug the unused fitting unless it will serve a second pump line or back-flush setup. Join clean flexible PVC with the appropriate PVC primer and cement.

Attach Liner and Weir

Leave a little liner slack, clean the bonding surfaces, apply the included silicone, fasten the weir with the stainless screws and only then trim the liner opening. Follow the manual’s fastening sequence.

Load the Filter Media

Set the two Matala mats horizontally in the bottom. Fill the mesh bag with selected biological media and place it above the mats.

Finish and Test

Install the landscape lid, complete the rockwork and use black waterfall foam where needed to direct visible flow. Test for even spillway flow and leaks before final landscaping.

View black waterfall foam

Care and Seasonal Maintenance

Protect the Bacteria Colony

Inspect the system as pond conditions change. When the waterfall media needs cleaning, rinse it with pond water when possible; chlorinated tap water can damage the beneficial bacteria.

Clean at the Right Time

The installation guide calls for a thorough waterfall-media cleaning about once per year, when water is coldest or below 50°F. Actual maintenance frequency varies with debris, fish load and feeding.

Prepare for Freezing Weather

In climates with prolonged freezing, remove the pond pump and follow its storage instructions. Rinse and store the removable media for winter, then reinstall it during spring startup.

Product Resources

Use the model-specific waterfall guide for the box installation and the broader pond guides for system planning and seasonal care.

Elite Waterfall Installation Guide (PDF) Water Garden Installation Guide (PDF) Pond Planning Guide (PDF) Pond Maintenance Guide (PDF) Spring Pond Care Guide (PDF) Fall Pond Care Guide (PDF) Blue Thumb Limited Warranty (PDF)

Installation Video

This official Blue Thumb pond-kit installation guide demonstrates how an Elite Waterfall Box fits into a complete pond build. Use the model-specific PDF above for PB1090 dimensions, 2- or 3-inch plumbing and exact waterfall-box assembly.

Video courtesy of Blue Thumb. Products, accessories and landscaping shown may vary; only the components listed on this page are included with PB1090.

Need Help Sizing the System?

Our Sales/Tech Team can help you review pond volume, planned waterfall width, plumbing size, pump flow at total dynamic head and the other components needed for your installation.

Call 888-619-3474 Email the Sales/Tech Team

Frequently Asked Questions

Is this a complete pond kit?

No. PB1090 is the biological waterfall box and its listed installation hardware. The pump, skimmer, flexible PVC, liner, underlayment, loose biological media, primer and cement, waterfall foam, rocks and gravel, electrical service and site work are selected separately.

What pump flow can the Large Elite Waterfall Box handle?

The maximum recommended flow is 10,000 GPH. Size the pump by its delivered flow at your installation’s total dynamic head—not by the pump’s zero-head rating—and stay within the waterfall box limit.

What size pond can it filter?

It is rated for ponds up to 6,000 gallons. Fish load, feeding, debris, sunlight, circulation and maintenance also affect filtration needs, so contact our Sales/Tech Team when the pond will carry a heavy biological load.

Can I use 2-inch or 3-inch flexible PVC?

Yes. The installation guide states that the 30-inch Elite Waterfall accepts either 2- or 3-inch flexible PVC. The box has two 3-inch spinweld fittings; use the supplied plumbing adapter arrangement and confirm the complete plumbing plan before installation.

Is biological filter media included?

Two green Matala filter mats and one mesh media bag are included. Loose biological media for the bag is not included. Our sizing guidance recommends 5 cubic feet of Bacti-Twist for the 30-inch box.

Where should the waterfall box be placed?

Place it opposite the skimmer to encourage circulation through the pond. It may sit at the pond edge or at the top of a stream. Compact the base, keep the box level from side to side and maintain access for media service.

How often should the waterfall media be cleaned?

Inspect it according to pond conditions. The guide recommends a thorough cleaning about once per year when the water is coldest or below 50°F. Rinse with pond water when possible so chlorine does not harm the beneficial bacteria.

What warranty applies to the waterfall box?

Blue Thumb’s lifetime limited plastics warranty covers Blue Thumb-branded engineered-plastic waterfall filters against manufacturing defects for the original purchaser, subject to proper installation and the complete written terms. The warranty does not extend a lifetime term to separately purchased pumps, lights or other equipment.
