60 Watt Transformer

SKU:
PB1588
|
UPC:
897570001588
$119.99
(No reviews yet) Write a Review
  • Automatically turns on at dusk; turns off 2, 4, 6, or 8 hours later.
  • Works with Halogen or LED lights.
  • Input: 120 Volts AC, 60 Htz, 2 Amps
  • Output: 12 Volts DC, 5.0 Amps
• One Year Warranty
Current Stock:
Blue Thumb | Low-Voltage Lighting Power

60 Watt Transformer with Automatic Dusk Timer

Power your compatible pond, fountain, waterfall, or landscape lights with the Blue Thumb 60 Watt Transformer. This programmable 12V DC power supply automatically activates lighting at dusk and offers four selectable shutoff durations, helping you enjoy your illuminated water feature without manually switching the lights on and off each evening.

60W Maximum Lighting Load
12V DC Low-Voltage Output
Dusk Automatic Activation
2–8 Hours Selectable Shutoff

Convenient Control for Outdoor Lighting

The PB1588 combines low-voltage power conversion with automatic lighting control. It is designed for compatible 12-volt LED and halogen lighting systems with a combined load of no more than 60 watts.

Automatic Dusk Activation

The built-in light-sensing function activates connected lighting when ambient daylight fades.

Four Timer Settings

Select a 2, 4, 6, or 8-hour operating period after dusk to match your preferred evening lighting schedule.

LED and Halogen Compatibility

Supports compatible low-voltage LED and halogen lighting. Verify the voltage, electrical requirements, and connectors of each light.

Compact Power Unit

Its approximately 4.25-inch square housing and 2-inch depth make it practical for many landscape lighting installations.

60 Watt Transformer Specifications

Product 60 Watt Programmable Transformer
Blue Thumb SKU PB1588
UPC 897570001588
Input 120V AC, 60Hz, 2A
Output 12V DC, 5.0A
Maximum Load 60 watts total
Lighting Types Compatible LED and halogen lights
Automatic Activation At dusk
Timer Options 2, 4, 6, or 8 hours
Dimensions 4.25" H × 4.25" W × 2" D
Warranty One year

Is This the Right Transformer?

Before ordering, confirm that your lighting system matches the transformer's electrical output and does not exceed its capacity.

Check Voltage

The transformer delivers 12V DC. The existing product listing also identifies compatibility with certain 12V AC/DC-rated LEDs. Confirm that your particular light accepts 12V DC.

Add the Wattage

Add the rated wattage of every connected light. The combined total must not exceed 60 watts.

Check Connections

Verify that your lighting cables, connectors, and any splitter are compatible with this transformer. A matching voltage alone does not guarantee a matching connection.

Consider Your Lighting Schedule

This model is suited to dusk-triggered lighting with a timed shutoff. If you need different control functionality, confirm your requirements before buying.

Important: Do not exceed the 60-watt maximum. This transformer is not a universal replacement for every 12-volt power supply. Verify output type, polarity, connectors, and system requirements before connecting your lights.

Planning Your Lighting Load

Determine your total power requirement by multiplying the wattage of each identical light by the number of lights. For mixed lighting systems, add the individual wattages together.

Example Total Lighting Load
4 × 3W lights 12 watts
6 × 5W lights 30 watts
4 × 10W lights 40 watts
3 × 20W lights 60 watts

These examples illustrate wattage calculations only. They do not establish connector or electrical compatibility for specific lights.

Installation Planning

1

Verify the Lighting System

Confirm each light's voltage, current or wattage requirements, and connector compatibility.

2

Choose a Suitable Location

Position the transformer near an appropriate electrical supply, following the product's installation instructions and applicable electrical safety requirements.

3

Connect Compatible Lighting

With power disconnected, make the required low-voltage connections using the correct wiring and connectors for your lighting system.

4

Select Your Timer Duration

Set the desired 2, 4, 6, or 8-hour shutoff period using the transformer's controls.

5

Test the System

Verify that the connected lights operate correctly and that the automatic dusk control responds as intended.

Electrical safety: Use a properly protected electrical supply suitable for the installation. Follow manufacturer instructions and local electrical codes, particularly near ponds or other water features. Confirm the unit's approved mounting and weather-exposure requirements before installation.

Related Lighting Products & Resources

Explore additional lighting components and power options. Compatibility should be confirmed before ordering.

Frequently Asked Questions

Does this transformer turn lights on automatically?

Yes. Its dusk-activated control automatically switches connected compatible lights on when ambient light levels fall.

What timer settings are available?

Choose a 2, 4, 6, or 8-hour operating period after dusk.

Can I use LED lights with this transformer?

Yes, provided the lights are electrically compatible with its 12V DC output and the combined load remains within 60 watts.

Can I connect more than one light?

Multiple compatible lights may be connected using an appropriate connection system, provided their combined power demand does not exceed 60 watts.

Will it work with 12V AC-only lights?

Do not assume so. The transformer's specified output is 12V DC. Lights rated exclusively for AC operation require verification before use.

Does the transformer include lights?

This product is listed as a transformer power unit rather than a complete lighting kit. Purchase any required lights and compatible connection accessories separately.

What warranty is provided?

The published product listing specifies a one-year warranty.

Questions Before Ordering?

Not sure whether this 60 Watt Transformer will work with your existing pond, fountain, waterfall, or landscape lights? Blue Thumb's knowledgeable team can help you review voltage, wattage, and connection requirements before you purchase.
